Hydraulic Dock Leveler 10T
The HLSH-07 combines a premium Bulff hydraulic pump with Japan NOK seals to deliver a dock leveler built for high-cycle, high-reliability warehouse operations. At 10 tons with a 2,280 mm platform, it adapts to truck heights quickly while lasting tens of thousands of loading cycles.
Capacity: 10 Ton | Length: 2,280 mm | Width: 1,830 mm | Height Adjust: -300 / +450 mm | Model: HLSH-07
Key Features
- Bulff gear pump – precise hydraulic pressure delivery
- Japan NOK seals – 60,000+ cycle industry certification
- FRF SAE100R2AT high-pressure hoses throughout
- 8 MPa working pressure ± 1 MPa tolerance
- HANMOKE control electronics – proven dock control system
- ≥ 99% uptime design specification
Technical Specifications
| Parameter | Value |
|---|---|
| Model | HLSH-10 | 1830×2280-10T |
| Rated Load | 10 Ton (22,000 lbs) |
| Platform | L2280 × W1830 × H490 mm |
| Pit Size | L2280 × W1870 × D500 mm |
| Height Adjust | -300 mm / +450 mm |
| Motor | 1.1 kW Bulff, 380V |
| Pump | Bulff gear pump |
| Seals | Japan NOK – 60,000+ cycles |
| Hose | FRF SAE100R2AT |
| Oil | 4.5 L, 46# anti-wear |
| Pressure | 8 MPa ± 1 MPa |
| Deck | Q235B checkered plate |
| Noise | ≤ 50 dB(A) |
| Uptime | ≥ 99% |
| Service Life | 15+ years |
Application Scenarios
Bridge dock-to-truck height gaps with push-button precision for shift-long throughput.
Rated to -35°C — the hydraulic system performs in sub-zero dock environments.
10-ton capacity handles heavy industrial forklifts in production dock bays.
Fast ≤ 30s adjustment time keeps freight terminal truck turnover efficient.
Frequently Asked Questions
Why is the Bulff pump specified?
Bulff is a recognized hydraulic pump brand. The gear pump design provides stable pressure delivery and long service life under continuous duty.
What hose standard is used?
FRF SAE100R2AT – an international standard high-pressure hydraulic hose suitable for 8 MPa operating pressure.
What is the designed uptime?
The HLSH-07 is designed to a ≥ 99% uptime specification with routine maintenance.
How does NOK seal quality compare?
Japan NOK is the world’s leading hydraulic seal manufacturer. Their seals are specified for dock levelers requiring 60,000+ operational cycles.
