Hydraulic Dock Leveler 10T
The HLSH-08 hydraulic dock leveler delivers industrial-grade performance through quality steel construction and proven hydraulic components. The Q235B Baosteel checkered deck and MIG-welded frame combine with Japan NOK seals for a leveler built to last through thousands of daily cycles.
Capacity: 10 Ton | Length: 2,280 mm | Width: 1,830 mm | Height Adjust: -300 / +450 mm | Model: HLSH-08
Key Features
- Baosteel Q235B checkered deck – leading Chinese mill steel quality
- 14# I-beam structural frame for maximum load distribution
- 4-coat high-temperature baked paint – superior adhesion and rust resistance
- MIG gas-shielded welding – uniform, pore-free weld joints
- Japan NOK hydraulic seals – 60,000+ cycle certified
- Complete HANMOKE controls and anti-collision bumpers
Technical Specifications
| Parameter | Value |
|---|---|
| Model | HLSH-10 | 1830×2280-10T |
| Rated Load | 10 Ton (22,000 lbs) |
| Platform | L2280 × W1830 × H490 mm |
| Pit Size | L2280 × W1870 × D500 mm |
| Height Adjust | -300 mm / +450 mm |
| Motor | 1.1 kW, 380V |
| Pump | Bulff gear pump |
| Seals | Japan NOK |
| Deck Steel | Baosteel Q235B, checkered plate |
| Frame | 14# I-beam structural steel |
| Coating | Sand-blast + 4-coat high-temp bake |
| Welding | MIG gas-shielded |
| Noise | ≤ 50 dB(A) |
| Service Life | 15+ years |
Application Scenarios
Bridge dock-to-truck height gaps with push-button precision for shift-long throughput.
Rated to -35°C — the hydraulic system performs in sub-zero dock environments.
10-ton capacity handles heavy industrial forklifts in production dock bays.
Fast ≤ 30s adjustment time keeps freight terminal truck turnover efficient.
Frequently Asked Questions
What makes Q235B steel suitable for dock levelers?
Q235B is a Chinese national standard structural steel with excellent weldability, consistent mechanical properties, and proven performance in dock leveler applications.
What is the coating process?
Parts are sand-blasted to remove scale, then given four spray coats followed by high-temperature baking – delivering superior paint adhesion and corrosion resistance.
How is welding quality ensured?
All structural welds use MIG gas-shielded welding. This produces uniform, bubble-free weld beads with full penetration and high tensile strength.
What frame steel is used?
The main structural frame uses 14# national standard I-beam structural steel, selected for its high moment of inertia and bending resistance.
