Hydraulic Dock Leveler 10T
Hydraulic Dock Leveler 10T
The HLSH-09 hydraulic dock leveler is the complete electric dock loading solution for logistics hubs and freight terminals. With a 15-year design life, Japan NOK seals, and Baosteel Q235B construction, it’s built for the long haul — cycle after cycle, shift after shift.
Capacity: 10 Ton | Length: 2,280 mm | Width: 1,830 mm | Height Adjust: -300 / +450 mm | Model: HLSH-09
Key Features
- 15-year design service life – lowest total cost of ownership
- ≥ 99% design uptime – minimizes loading dock downtime
- Japan NOK seals – 60,000+ cycles certified
- Dual voltage option: 380V standard, 220V available
- Q235B Baosteel steel deck and frame
- Full HANMOKE electronic controls package
Technical Specifications
| Parameter | Value |
|---|---|
| Model | HLSH-10 | 1830×2280-10T |
| Rated Load | 10 Ton (22,000 lbs) |
| Platform | L2280 × W1830 × H490 mm |
| Pit Size | L2280 × W1870 × D500 mm |
| Height Adjust | -300 mm / +450 mm |
| Motor | 1.1 kW Bulff, 380V / optional 220V |
| Seals | Japan NOK – 60,000+ cycles |
| Oil Capacity | 4.5 L |
| Working Temp | -35°C ~ +65°C |
| Uptime | ≥ 99% |
| Noise | ≤ 50 dB(A) |
| Weight | ≥ 780 kg |
| Service Life | 15+ years |
| Warranty | Contact us |
Application Scenarios
Bridge dock-to-truck height gaps with push-button precision for shift-long throughput.
Rated to -35°C — the hydraulic system performs in sub-zero dock environments.
10-ton capacity handles heavy industrial forklifts in production dock bays.
Fast ≤ 30s adjustment time keeps freight terminal truck turnover efficient.
Frequently Asked Questions
What is the designed service life?
The HLSH-09 is designed for 15+ years of service with proper maintenance, offering an excellent total cost of ownership.
What uptime can I expect?
Design uptime is ≥ 99%, meaning less than 88 hours of unplanned downtime per year under normal operating conditions.
Is a 220V version available?
Yes. The standard supply is 380V, but a 220V/50Hz motor configuration is available upon request.
What is included in the delivery?
The complete unit includes the dock leveler platform, hydraulic power unit, HANMOKE control box, anti-collision bumpers, and maintenance safety bar.
